ACME LP-6020 Fiber Laser Tube Cutting Machine – New
Details
- Fiber laser source,use IPG or Raycus laser,with better performance,ultra-low noise,high stability and ultra-long lifetime for 100000 hours.
- Raytools fiber laser cutting head with anti-crash function,good sealed,high pressure resistant. Auto-tracking system and anti-crash and stop system can protect good cutting quality and longer the life of lens.
- Control panel, you can design the patterns you want here. Or you can import the patterns via USB flash drive.
- The tempered heavy duty machine bed,good rigiding and high precision, can keep the bed from being used for 20 years without deformation.
- Imported high performance reducer,gear and rack.
- Chiller,dual-temperature,cooling for laser source and laser head.
Contact Us To Buy
If you are interested in purchasing this machine or would like to find out more details. please complete the form below or call Martin on 07538 673632 and we will get back to you as soon as possible.
ACME LP-6020 Fiber Laser Tube Cutting Machine – New
Working area – 6000 mm * 220 mm
Laser power – 1000W-1500W
Laser type – Fiber laser, water-cooling
Laser wavelength – 1070-1080nm
Running speed – 0-70m/min
CNC or Not – CNC
Resetting position Accuracy – ≤±0.02mm
Control software – Cypcut
Operating temperature – 0 – 40 ° CNG
Graphic format supported – IGS (Available PRO/E. UG, Solid works Photo)
Transfer method – Double drive rack and pinion
Drive modor – Imported servo motor and servo drive
Applied material – Carbon steel/SS and other metal plates
Warranty – 2 Years
Fiber Laser Cutting Machine – ACME
Laser – Raycus/ IPG/MAX
Laser Cutting Head – Raytools
X, Y axis Rack and Pinion (Double Drive) – Taiwan YYC
Reducer – France Motoreducer
Control System – Cypcut
AC Servo Motor – Yaskawa Servo Sigma 7
X, Y, Z axis Motor and Driver – Yaskawa Servo Sigma 7
Guide Rail – Taiwan PMI 35mm
Pneumatic Components – SMC
Electrical Components – Schneider
Computer – Made in China
Fiber Laser Cutting Equipment is suitable for metal cutting with Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring Steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc.
Fiber Laser Cutting Machine is widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts, Nameplates, etc.
